Requested Project – Falls Test Tower |End Day 19 set 17|

Drop Test Tower

Goodnight, request a quote for the supply of a project for a metallic structure,model photo attached.
Must contain structural calculation memorial, construction details (drawings), modelo 3D, detailed material list, load plan on supports and ART.
Below are technical data and illustrative photo:

– Height: 9,5m (floor to top of highest beam)
– Natural frequency: 200Hz (measured on the vertical axis, through the center of the larger yellow beam). Question: when meeting this requirement, would automatically answer a lower frequency (ex: 100Hz)?
– Maximum elastic deformation: 1mm, when a static force of 20kN is applied at the same point
– Internal width of the “largest beam”: 3,5m
– Internal width of the “smaller beam”: 1,5m(where is the hydraulic cylinder)
– The yellow beams will have height adjustment (pinned supports as per photo).
– Tensile test (on the right) will have a maximum load of 10T. (We already have the cylinder and hydraulic system)
– Hoist support: Displacement in the horizontal plane of approx.. 1m (“outside” the yellow beam)
– Maximum hoist load: 500kg
– Rear part of the larger yellow beam: must contain a “container” to accommodate the excess chain from the hoist when the hook is retracted.
