Design Requested - Horizontal filter press with filtering capacity of about 200 T/h |End Day 28/06/2020|

Project Factory28 April 202028 April 2020Access N1FP, Filter press designer, filter press project

Request for FP Projects Horizontal filter press with hydraulic drive geared towards mining with filtering capacity of about 200 ton / hour. I'm looking for a designer with experience in the area who can suggest improvements to the process.

FP N3 Applications: CEMA Standard Screw Conveyor Complete Calculation Worksheet

Project Factory27 April 202030 december 2023Access N3, App, Calculation of Screw Conveyor or Screw Conveyor, FPH, HFPFP Applications, I calculate plates and helicoids helical conveyor, helical conveyor power calculation, Screw Conveyor Calculation Worksheet, N3 access worksheets, Design and engineering calculation worksheets, Screw Conveyor Project

FP Applications CEMA Standard Screw Conveyor Complete Calculation Worksheet: Spreadsheet for calculation and design of screw conveyors, calculating and specifying the following output information: Main output data: -Engine Power -Equipment Transport Capacity -Transport Speed -Gutter Configuration -Helicoid Configuration -Item Weights -Shaft Dimensioning -Immediate Bearing Configuration -Screw Dimensioning -Bearing Bushing Geometry -External Bearings -Retainers -Selection Tables Quick -Including PDF CEMA Manual

FP Projects: Crane Test Device

Project Factory25 April 202030 december 2023Project Catalog, Project Catalog 301 - 400, Cargo and Passenger Elevators, FPH, Published Projects, Mechanical ProjectsFP, mechanical designer, overhead crane, crane test device design, Mechanic project, MECHANICAL PROJECTS

FP Published Projects: Design of crane test device with 60T capacity. Solidworks CAD drawing and calculations. Contact us for more details about the project..

Project Requested - Exhaust Project capable of sucking smoke from a Plasma Cutting table |End Day 15 May 20|

Project Factory23 April 202023 April 2020Access N1FP

FP Project Request I need a project for an exhaust fan for a smoke aspiration from a CNC plasma cutting table, table according to attached project, because today the smoke from the cut is hampering the progress of production. I need the hood project to manufacture it in our factory.

Requested Project - 4mm Plate Calender |End Day 17 Apr 20|

Project Factory11 April 202011 April 2020Access N1FP, MECHANICAL PROJECTS

FP Project Request Hello I would like to design the calender length 2 meters wide and plate thickness up to 4 mm

Requested Project - Cleaning Products Factory |End Day 30 Apr 20|

Project Factory9 April 202023 April 2020Access N1cleaning product factory, FP, cleaning products factory project

FP Project Request Cleaning products factory layout with cap. Production up to 5000kg/day, contemplating your equipment, from dosage to potting.

Requested Project - Calender Project |End Day 10 Apr 20|

Project Factory6 April 20206 April 2020Access N1FP

FP Project Request I am interested in a project of a calender for sheet metal 3/4 for 2 meters wide

FP Projects: Double Bag Filter of 3 elements

Project Factory6 April 202030 december 2023Project Catalog, Project Catalog 301 - 400, FPH, Published Projects, Mechanical Projectsdouble bag filter, FP, mechanical designer, filter design, double bag filter design, Mechanic project, MECHANICAL PROJECTS

Publicized Projects FP Equipment entirely manufactured in AISI-304 stainless steel; General dimensions of the side: Ø513mm x 680mm high; ASME Torispheric Top Top 10% swivel with davit and 12 (dose) grip handles; ASME Torispheric Bottom Top 10%; Internal flange with drilling for support of 03 (three) filter elements each filter; 03 (three) “CREPINAS” spiral bag holder…

FP Projects: Bucket elevator for grains with high cohesion

Project Factory1 April 202030 december 2023Project Catalog, Project Catalog 301 - 400, Cargo and Passenger Elevators, Agricultural Equipment, FPH, Published Projects, Mechanical ProjectsFP, mechanical designer, Mechanic project, MECHANICAL PROJECTS

FP Published Projects – Capacity: 130 t / h Height: 30 meters power: 15 cv speed: 1,6 m/s Process: transport of luscious grains
